Veratron Oil Pressure Sensor – 1/8″-27NPT Thread – 10 Bar [B002008]

Oil Pressure Sensor – 1/8″-27NPT Thread – 10 Bar

Veratron’s Pressure Sensors deliver a stable quality reading during a long lifespan. They have excellent anti-vibration performance and a wide operating temperature range.

The sensors can be used in a wide range of applications.

All sensors come with a sensor output and an insulated ground pin.

Features:

• Function – Engine oil pressure, transmission oil pressure
• Thread – 1/8″-27NPT
• Calibration – 10-184 Ohm
• Measurement Range – 10 bar
• Output Signals – Resistive
• Wide Operating Range – -25 to 120°C
• Insulated ground pin

Quick Guide (pdf)
