The Deckboat 40-G3 Electric Anchor Winch with AutoDeploy is an essential tool for any boating enthusiast, offering effortless control over your anchor operations. With its automated system, you can easily raise and lower your anchor at the press of a button, ensuring a secure and stable hold every time.
Features
- Automatic anchor deployment and retrieval with user-friendly buttons
- AutoDeploy function halts the winch when the anchor reaches the seabed, maintaining your boat’s position
- Robust 12 V all-steel gear motor for high efficiency and reduced battery consumption
- Excellent holding power with a maximum anchor capacity of 40 lb
- Sleek design suitable for boats up to 26 feet
Technical Specifications
| Parameter | Details |
|---|---|
| Boat Size | Up to 26′ |
| Anchor Capacity | 40 lb |
| Anchor Deployment | Power Down or AutoDeploy Down |
| Rope Speed Down | 70 FPM |
| Rope Speed Up | 65 FPM |
| Power | 12 V |
| Dimensions (L x W x H) | 19.5″ x 9.75″ x 5.75″ |
| Vertical/Horizontal | Horizontal |
| Rope Diameter | 3/16″ |
| Freefall | No |
| Box Dimensions | 7″H x 10″W x 16″L |
| Weight | 13.95 lbs |
| UPC | 666996102199 |
What’s in the Box
- Winch with integrated anchor roller
- 100′ of 3/16″ pre-wound double braid anchor rope
- Sealed membrane UP/DOWN/AutoDeploy switch
- 17′ marine-grade battery wire
- Assembly hardware
- Instruction manual
Note: Anchor not included. Sold as an individual unit.
Important Information
WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, visit .
Owner’s Manual
For detailed instructions and maintenance information, please refer to the .
