The 12″ ATLAS™ Hole Shot Plate with Transducer Cut Out is a premium hydraulic solution designed specifically for marine applications. Engineered to support the most powerful V6 and four-stroke engines, this jack plate ensures efficient and reliable lifting of your outboard engine, enhancing your boating experience with its advanced technology and robust construction.
Key Features
- Next-Generation Design: Crafted for heavy-duty performance, the ATLAS™ Hole Shot Plate sets a new standard in jack plate engineering.
- Polymer Rod & Slot Lifting Mechanism: Our high-tech polymer components guarantee smooth and trouble-free operation, even under extreme conditions.
- One-Piece Hydraulics: Integrated hydraulic system offers both speed and self-contained lifting action, ensuring quick and efficient engine lifts.
- Rapid Lifting Capability: Easily lift the heaviest outboards from bottom to top in under 8 seconds, minimizing downtime.
- 12-Inch Setback: Provides versatile mounting options to accommodate a wide range of engine configurations.
Specifications
| Specification | Details |
|---|---|
| Model | AHJ-12V-DP |
| Setback | 12 inches |
| Engine Compatibility | V6 and four-stroke marine engines |
| Lift Time | Under 8 seconds |
| Material | High-strength polymer and hydraulics |
Benefits
- Durability: Built to withstand the harsh marine environment, ensuring long-lasting performance.
- Efficiency: Quick lifting reduces maintenance time, allowing you to spend more time on the water.
- Ease of Installation: Designed for straightforward mounting and integration with existing systems.
- Reliability: Trusted performance from T-H Marine, a leader in hydraulic design.
- Safety: Enhanced lifting mechanism minimizes the risk of engine damage during lifts.
Installation Instructions
Installing the ATLAS™ Hole Shot Plate with Transducer Cut Out is simple and hassle-free. Follow these steps:
- Ensure your outboard engine is securely positioned.
- Align the 12″ setback jack plate with the designated mounting points on your engine.
- Secure the jack plate using the provided bolts and ensure all connections are tight.
- Connect the hydraulic transducer as per the included wiring diagram.
- Test the lifting mechanism to ensure proper operation before final use.
Warranty & Support
We stand behind the quality of our products. The ATLAS™ Hole Shot Plate comes with a 2-year warranty covering any defects in materials or workmanship. For installation assistance, troubleshooting, or any other support, our dedicated customer service team is here to help.
